Suport de carretons elevadors Push Pull

Inici / Tots els fitxers adjunts / Suport de carretons elevadors Push Pull

Suport de carretons elevadors Push Pull
A push-pull forklift attachment is a material handling device designed to move long and heavy loads with ease. It is attached to the forklift and helps in pushing and pulling large and heavy loads, making the movement of goods from one place to another much easier. This attachment is especially useful for handling long and narrow loads such as pipes, steel beams, and sheets.

The push-pull attachment is made up of two arms that are attached to the forklift's tines. These arms can be extended to accommodate the length of the load being transported. The arms also have rollers on their ends that make it easier to move the load. The rollers can be adjusted to the desired height, making it possible to transport loads of different heights and sizes.

This attachment is easy to install and operate. It can be easily attached to the forklift and removed when not in use. The arms can be extended or retracted to accommodate the size of the load being transported. The attachment also comes with hydraulic control valves that make it possible to control the speed and direction of the load.

The push-pull forklift attachment is ideal for handling long and narrow loads such as pipes, steel beams, and sheets. It reduces the risk of damage to the load and the environment, as it allows for precise control over the movement of the load. The attachment also helps to increase productivity by reducing the amount of time and effort required to transport the load.

In conclusion, the push-pull forklift attachment is a useful tool for transporting long and heavy loads. It makes material handling easier, reduces the risk of damage to the load and the environment, and increases productivity. This attachment is a must-have for any company that handles long and narrow loads.

Avantatges del producte

HUMAI forklift push/ pull forklift attachment with China Xinchai C490 engine, hydraulic transmission,USA EATON hydraulic assisted steering valve,SHIMADZU oil pump,full suspension chassis.It is widely used to handing all kinds of goods,such as pallet,steel,brick etc.Shantui has cooperated with KOMATSU more than 30 years,all the product was made under KOMATSU standard.

Vídeos

Motor
Model
HUAMAI C490
Sortida nominal
40/2650
Kw / rpm
Par nominal
165/1800
N · m / rpm
Núm. De cilindre
4
B × traç
90 × 105
mm
Desplaçament
2.7
L
Dimensions
Alçada per elevació
3000
mm
LxWxH (amb / sense forquilla)
3779 (2709) x1226x2140
mm
Radi de gir
2450
mm
Angle d'inclinació del màster (F / R)
6/12
Titulació
Rendiment
Velocitat de recorregut (càrrega completa / sense càrrega)
19/20
Km / h
Velocitat d’elevació (amb / sense) càrrega
420/450
mm / seg
Capacitat màxima
20
%
Pes propi
4560
Kg
Rodes i pneumàtics
Front
28 × 9-14-14PR
Part posterior
6.50-10-10PR
Ampliació de rodes
1700
mm
Desplaçament del terreny de joc (pal)
110
mm

Detalls ràpids

Estat: Nou
Lloc de procedència: Xiamen, Xina (continental)
Nom de marca: HUAMAI
Número de model: HUAMAI30
Tipus: Camió de paletes amb motor
Power Souce: Motor Dièsel
Capacitat de càrrega nominal: 3000kg
Màx. Alçada d'elevació: 8000mm
Min. Alçada d'elevació: 3000mm
Longitud de la forca: 1070mm
Amplada de la forquilla: 122mm
Mides generals: 3829x1226x2140mm
Certificació: ISO9001 / ISO14001 / CE
Servei postvenda subministrat: enginyers disponibles per a la maquinària de servei a l'estranger
Accseeory: push / pull
Mida de la forquilla: 1070 * 122 * 40mm
Centre de càrrega: 500 mm
Pneumàtic: Pneumàtic
Tipus de potència: Dièsel
Color: Groc
Base de rodes: 1700mm
Bateria: 12V / 60Ah
Capacitat del tanc d’oli: 50 litres
pressió de funcionament: 17,5Mpa
